T1 radio transmitter - FM radio - LED alarm and flashlight - Baofeng (BF-T1)

T1 radio transmitter
Baofeng brand (BF-T1)

The T1 is a miniature multibano FM transceiver with wide reception frequency coverage, which provides local two-way amateur communications with unmatched monitoring functionality

Features:
FM Broadcast radio receiver (65-108 Mhz)
Integrated alarm and LED flashlight
Max 20 channels
Time countdown (0.5 / 1 hour / ... / 8 hours)
Voice message
VOX (voice command transmission)
50 CTCSS tones / 104 DCS codes / non-standard tones available
Tail tone elimination
Battery saving
Wide / narrow band selection
SOS call waiting
PC programming (programming cable not included)

General
UHF frequency range: 400-470 MHz
Channel n. 20
Frequency stability ± 2.5 ppm
Step frequency 12.5 / 25 Kz
Antenna impedance 50Ω
Operating voltage DC 3.7 V.
Working temperature from -20 ° C to + 60 ° C
Battery capacity H-1500mAH (lithium ion battery)
Battery life approximately 12 hours
Dimensions L x H x D 108 x 55 x 21 mm including the antenna
Weight 99 gr

Transmitter
Output power 0.5 W / 1 W.
Modulation mode 16kΦF3E / 11kΦF3E
Maximum deviation ≤5kHz (wide) / ≤2.5kHz (narrow)
Spurious radiation ≤7.5μW
Adjacent Ch. power ≤-65dB (wide) / ≤-60dB (narrow)
Audio distortion <5%
SNR ≥ -45dB / ≥ -40dB
Frequency deviation CTCSS / DCS (W / N band) 0.7 ± 0.1 kHz (wide) / 0.4 ± 0.1 kHz (narrow)
Intermediation sensitivity 8-12mV
Transmission current ≤ 1000mA
Receiver
Sensitivity <0.25μ V (12 dB SINAD)
Audio power 1W
Inter modulation Interference resistance ≥ 65dB (W), ≥ 60dB (N)
Adjacent channel selectivity (W / N band) ≥ 65dB (W), ≥ 55dB (N)
Audio distortion 5%
Reception current ≤ 380 mA

The package includes:
-1 x Baofeng T1 Mini Walkie Talkie
-1 x 3.7 V 1500 mAh Original Baofeng lithium ion battery
-1 x antenna
-1 x lanyard
-1 x belt clip
-1 x ENG manual
-1 x USB charging cable
-1 x PTT Free earphone
