Thermal Image Scope HIKMICRO THUNDER ZOOM 60mm
HIKMICRO BREND
Model THUNDER ZOOM
Detection Range 3000 m
Thermal Image Scope HIKMICRO THUNDER ZOOM
HIKMICRO BREND
Model THUNDER ZOMM 6 mm
Detection Range 3000 m
HIKMICRO THUNDER ZOOM 2.0 Thermal Viewer 60MM
The first 20mK thermal riflescope with optical zoom
Equipped with a 640 thermal detector and a lens
35mm/F0.9 and a 60mm/F1.1 lens offering a large FOV at 22m and a magnification starting from 1.8x, the TQ060 2.0 is perfect for long-range hunting up to 3000m both in the woods and in the field, TQ60Z 2.0 can be a useful companion.
Sharp images for incredible detail recognition
Vivid, informative and layered images
With a very high thermal sensitivity detector (NETD<20mK) combining a powerful thermal imager up to 640x512 @12μm @ F0.9/F1.1, the HIKMICRO THUNDER ZOOM 2.0 thermal riflescope guarantees sharp, informative and layered images even in the presence of minimal temperature differences.
High Quality Enlarged Image Thanks to Optical Zoom
The Broad Lens Improves Identification Ability
The large lenses of the THUNDER ZOOM 2.0 ensure a better ability to capture thermal radiation, without losing any detail. You can easily distinguish the target from the background with different lens combinations.
The Optical Zoom Allows You to Maintain High Image Quality
HIKMICRO THUNDER ZOOM 2.0 offers dual FOV using optical zoom technology. By using double lenses, the image is enlarged and still maintains high quality. This technology is the first to be applied to a 20mK thermal scope.
Single / separate zeroing
One-Time Zeroing Zero first with the small FOV lens, then switch to the other lens; the zero position will be automatically adjusted. That is, it can zero once before using, saving time and bullets!
Please note: It should zero the 50mm lens in TH50Z 2.0 or the 60mm lens in TQ60Z 2.0.
Separate zeroing: It can also zero both lenses respectively to achieve better gaming accuracy.
Lightweight Magnesium Alloy Design for Long-Lasting Use
Magnesium Alloy Design for Long-Lasting Use
Magnesium alloy design; extreme working temperature from -30℃ to 55℃. The improved stability of THUNDER ZOOM 2.0 satisfies long-time use.
High shock resistance up to 1000g/0.4ms
The THUNDER ZOOM 2.0 of the HIKMICRO thermal riflescope features high shock resistance even on larger calibers up to .375 H&H, 12 gauge and 9.3 × 64.
Powerful battery performance,
non-stop game
Long time operation, support direct charging
TWO new batteries extend the battery life of THUNDER ZOOM 2.0 to 21 hours and can be charged directly in the device. Furthermore, the battery pack has superior performance to others, especially in a low temperature environment.
Improved User Interface, Easy to Use
Quick settings allow for superior performance when hunting
Adjusting the brightness and contrast in the quick menu helps you conveniently recognize image details with just a few clicks.
The PIP function is activated with just ONE press (with the digital zoom button).
Multiple Lattice Profiles
5 groups of reticles with 4 colors and 10 reticle types to choose from, multiple profiles can be configured and saved for more convenience in THUNDER ZOOM 2.0 thermal optics.
Long Range Detection
Equipped with an advanced image detector and superior quality lenses, a 1.7 meter object can be detected by the THUNDER ZOOM 2.0 HIKMICRO thermal spotting scope from a distance of up to 3000 meters, even in complete darkness.
Share Your Exciting Moments
HIKMICRO Sight is a comprehensive APP designed for external devices. It is an all-in-one solution that supports previewing, remote control, browsing and downloading, sharing your amazing moments, and firmware updates.
Characteristics:
Thermal Module | |
Image Sensor | VOx Uncooled Focal Plane Arrays |
Max. Resolution | 640 × 521 |
Frame rate | 50 Hz |
Pixel Interval | 12 μm |
NETD | <35 mK (@ 25 °C),F# = 1.0 |
Lens (Focal Length) | 19 mm |
Detection range | 1800 m/ 3000m |
Field of View | 12.5° × 10/°21.9 m x 17,6m 7,3°x 5,9/12.8m x 10.2 m |
Min. focusing distance | 0,5 m |
Aperture | F1.0 |
Magnification | 1,8x to 14,6x\3.1x to 25.0x(8x) |
Image Display | |
Display | 1024 × 768, 0.39 inch, OLED |
Palettes | Black Hot, White Hot, Red Hot, Fusion |
FFC | auti,manual,exsternal correction |
Exit pupil | 6 mm |
Eye relief | 45 mm |
brightness adjustment | yes |
tone adjustment | cold warm |
System | |
Record video | On-board video recording |
Capture Snapshot | Yes |
Standby mode | Yes |
Storage | Built-in EMMC (16 gb) |
DPC | Yes |
Hotspot | Yes |
Hot track | Yes |
Reticle | no |
Distance measurement | Yes |
reciol-activation recording | Yes |
audio recording | Yes |
Max recoil | 1000g/0.4 ms |
image calibration | Yes |
Power Supply | |
Battery Type | replaceable and rechargeable Li-on battery |
Battery Operating Time | >6.5h (25°c,wit hotspot off) |
Type-C power supply | 5 VDC ,2A supports external power supply |
General | |
Work Temperature/Humidity | - 30 °C to 55 °C (- 4 °F to 131 °F) |
Protection Level | IP67 |
Dimension | 254,4 mm × 68.50 mm × 80.6 mm |
Weight | 843 g without eyepiece and batteries |
Order by Fax!
Download the form, fill it in and send it to the following number:
0549 991251
